Screw Diameter: ⌀45
Film Width: 100-700mm
Film Thickness: 0.01-0.25mm
Output: 80kg/h
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitriding, So it is sound in hardness, durable in corrosion resistance.
The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity.
It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE).
It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
| Model | GR-SJ700 | GR-SJ900 | GR-SJ1100 |
| Screw Diameter | ⌀45 | ⌀50 | ⌀55 |
| L/D | 32:1 | 32:1 | 32:1 |
| Fim Width | 100-700mm | 100-800mm | 200-1000mm |
| Film Thickness(single) | 0.01-0.25mm | 0.01-0.25mm | 0.01-0.25mm |
| Output | 80kg/h | 100kg/h | 160kg/h |
| Power of Main Motor | 18.5KW | 22KW | 30KW |
| Dimension | 5.0x2.6x5.0m | 5.0x2.8x5.0m | 5.0x2.9x5.0m |
| Weight | 2.0T | 2.4T | 2.8T |
Screw Diameter: ⌀50*3
Film Width: 800mm
Film Thickness: 0.01-0.10mm
Output: 120kg/h
Screw Diameter:⌀60
Film Width:1200mm
Film Thickness:Single Face 0.002s-0.15s (HDPE)
Output:120kg/h
Screw Diameter:⌀60
Film Width:200-1200mm
Film Thickness:0.01-0.25mm
Output:160kg/h
