GR-600
Zipper Lock Film Blowing Extruding Machinery
Discover the pinnacle of innovation with Guoran's Zipper Lock Film Blowing Extruding Machinery, proudly crafted in our state-of-the-art factory in China. Guoran's factory in China stands as a beacon of technological advancement, and our Zipper Lock Film Blowing Extruding Machinery reflects our commitment to delivering top-tier equipment that meets the evolving needs of various industries. Trust us as your reliable partner in advancing your production capabilities with this sophisticated and customizable extruding machinery.

Screw Diameter: ⌀50

Film Width: 500mm

Film Thickness: 0.03-0.11mm

Output: 30kg/h

GET A QUOTE
Compare
DESCRIPTIONS

The Guoran high qulity Zipper Lock Film Blowing Extruding Machinery is the perfect solution for producing zip lock film featuring a distinctive red line and color strip. Zipper bags produced by this equipment find extensive applications in food packaging, medicine, hardware, and various commodities. These bags are designed for easy opening and reclosing, ensuring a secure seal. The primary material used is LDPE, a reliable choice for such packaging needs.



Zipper Film System:

- The machine features a zipper extrusion system that simultaneously produces the zipper during the film extrusion process. This integrated system allows for an efficient workflow, potentially in-line with extruder-printer-bag making processes. Each extrusion die supports a specific film width.



Double Bag System:

- This innovative system enables the extrusion of small bags with two zippers, which are then cold-slitted during the bag-making process. This approach enhances efficiency and provides versatility in the production of zipper bags.

In summary, this equipment is designed to streamline the production of high-quality zipper bags with unique features such as a red line and color strip. Its flexibility, efficiency, and ability to integrate seamlessly into bag-making processes make it an ideal choice for various industries requiring reliable zip lock film production.

MACHINE HIGHLIGHTS

Red Line Extruder:
- Equipped with an extruder specialized for creating a red line on the opening of the zipper bag, enhancing its visual appeal and functionality.

Color Strip Extruder:
- Offers the option of an extruder dedicated to incorporating a color strip into the zipper bag, allowing for customization and easy identification.

Frequency Converter Speed Control:
- Utilizes a frequency converter for precise speed control, ensuring optimal performance and flexibility in production.

PARAMETERS
Model GR-900
Screw Diameter ⌀50
L/D 32:1
Fim Width 500mm
Film Thickness(single) 0.03-0.11mm
Output 30kg/h
OPTIONAL ACCESSORIES
GT-A1300 Horizontal Slitting Machine
Optical and Electrical Correction Frame
JL-8T Hydraulic Punching Machine
Auto Loader
FS-250 Plastic Grind Machine
BGDC-200【300】Plastic Film Impactor
Taiwan OUGUAN Fan Blower
Mould
Vertical Mixer
Horizontal Mixer
Air Cooler
Pneumatic Punching
Hdpe Air Ring With Double Tuyere
Reducer
Servo Motor
GT-A1300 Horizontal Slitting Machine
Optical and Electrical Correction Frame
JL-8T Hydraulic Punching Machine
Auto Loader
FS-250 Plastic Grind Machine
BGDC-200【300】Plastic Film Impactor
Taiwan OUGUAN Fan Blower
Mould
Vertical Mixer
Horizontal Mixer
Air Cooler
Pneumatic Punching
Hdpe Air Ring With Double Tuyere
Reducer
Servo Motor
RECOMMENDED MODELS
Biodegradable Mini Extrusion Film Blowing Machine

Screw Diameter:⌀50

Film Width:800mm

Film Thickness:Single Face 0.002s-0.15s (HDPE)

Output:80kg/h

Ordinary Gravure Machine

Printing Width:600mm

Printing Speed:30-70m/min

Printing Cylinder Diameter:Φ70-300

Priting Color:4Colors

Gravure Printing Machine

Max.web width:650-2050mm

Printing speed: 320m/min

Dia. of unwind and rewind:φ600,800, 1000mm

Dia. of printing cylinder:φ100-300mm
