| Model |
GR55-1100 |
| Maximum Film Width |
1000 (mm) |
| Minimum Film Width |
200 (mm) |
| Thickness of film |
Single Face 0.002s-0.15s (HDPE) |
| Maximum output |
120kg/h |
| Dimension |
L5200*W3200*H5400 |
| Screw Diameter |
ø55 |
| Screw Length-diameter ratio |
32 : 1 |
| screw Material |
38CrMoAIA |
| Reducer |
146 |
| Extruder main motor |
22KW |
| Screw Speed |
0-120min |
Application Scope of Guoran High Speed PE LDPE HDPE Blown Film Extruder:
The plastic film generated by the High Speed PE LDPE HDPE Blown Film Extruder holds diverse applications based on its materials and properties. It is well-suited for high-end film packaging, plastic bag films, protective films, and more. Leveraging its excellent barrier properties, the film is ideal for preserving freshness, providing moisture-proofing, frost resistance, oxygen insulation, and oil resistance. This makes it widely applicable in both light and heavy packaging scenarios, including fresh fruits, meat products, pickles, fresh milk, liquid drinks, medical supplies, and beyond.
Common Maintenance Methods for Plastic High Speed PE LDPE HDPE Blown Film Extruders:
1. Proper Storage: Place the High Speed PE LDPE HDPE Blown Film Extruder in a ventilated and dry environment to maintain the appropriate working temperature.
2. Lubrication: Regularly lubricate machine parts every few days of operation to ensure smooth functioning.
3. Dust Removal: Conduct regular dust removal to keep the entire machine clean. When not in use, unplug the power source, cover it with a cloth, and implement dustproof measures.
4. Cooling Procedure: If the machine runs for an extended period, turn on the cooling fan before shutting down. Shut down the machine after the temperature drops to prevent damage to the high-temperature belt.
5. Belt Cleaning: Regularly clean the high-temperature belt of dust to ensure sealing quality.
6. Part Replacement: Replace seriously worn parts promptly to prolong the overall machine's lifespan. Neglecting to replace worn components may adversely affect the machine's operational efficiency.
By adhering to these maintenance practices, users can ensure the longevity, efficiency, and optimal performance of their plastic High Speed PE LDPE HDPE Blown Film Extruders, allowing them to capitalize on the machine's capabilities effectively.
