GRQF800-1300

Fully Automatic Woven Bag Cutting And Sewing Machine

Plastic woven bags, in a broad sense, refer to fabrics made of plastic filaments. This product adopts unique technology, based on the cutting and sewing production process of woven bags, and based on the current rising labor costs and the backwardness of the production process, a one-stop fully automatic professional equipment is professionally designed to produce standard and neat products.

Bag Width:450-800mm

Bag Length:550-1300mm

Substrate Specifications:∅1100x1200mm

Production Speed:23-60Bag/min

GET A QUOTE →

Fully Automatic Woven Bag Cutting And Sewing Machine

upload/1c/202507/fully-automatic-woven-bag-cutting-and-sewing-machine-2.jpg

DESCRIPTIONS
MACHINE HIGHLIGHTS
PARAMETERS
CORE COMPONENT
OPTIONAL ACCESSORIES

DESCRIPTIONS

The production process fully achieves humanized service. It can completely replace the previous heavy physical labor. The process is divided into rolling up-cutting-folding-sewing the bottom-bag collection.

MACHINE HIGHLIGHTS

Automatically complete the fixed-length thermal cutting and bottom sewing of color-printed or blank woven tube cloth, saving labor.

Adopt touch screen setting, PLC control, servo motor drive, and accurately control the bag length.

After thermal cutting, the bag is smoke-free and non-sticky, and easy to open.

Automatic counting. The bag can be fed in a stack.

Pneumatic rolling up, easy to operate and labor-saving.

PARAMETERS

Name	Unit	Parameter	Remark
Working Speed	Bag/min	23-60	Depends on the sewing machine speed (2000r/min), needle pitch and bag width
Bag Width	mm	450-800	Width size model can be customized
Bag Length	mm	550-1300	Length size model can be customized
Cutting Accuracy	mm	±2
Substrate Specifications	mm	∅1100x1200	max
Substrate Weight	Kg	500	max
Folding Width	mm	20-40	With single and double folding former
Automatic Deviation Correction	mm	130
Line Breakage Shutdown		Automatic Detection
Material Stack Quantity	Bag	1-100	Can be set by yourself
Machine Input Voltage	V	380	According to customer needs
Bag Cutting Method	Electric Cutting	Hot Cutting Smokeless Knife	Customizable cold cutting
Material Collection Method		Carbon Rod Slapping	Electric flapping and collecting
Machine Power	KW	13	Operating power: 9KW
Machine Weight	T
Machine Appearance	m		LxWxH

OPTIONAL ACCESSORIES

GT-A1300 Horizontal Slitting Machine

Optical and Electrical Correction Frame

JL-8T Hydraulic Punching Machine

Auto Loader

FS-250 Plastic Grind Machine

BGDC-200【300】Plastic Film Impactor

Taiwan OUGUAN Fan Blower

Mould

Vertical Mixer

Horizontal Mixer

Air Cooler

Pneumatic Punching

Hdpe Air Ring With Double Tuyere

Reducer

Servo Motor

GT-A1300 Horizontal Slitting Machine

Optical and Electrical Correction Frame

JL-8T Hydraulic Punching Machine

Auto Loader

FS-250 Plastic Grind Machine

BGDC-200【300】Plastic Film Impactor

Taiwan OUGUAN Fan Blower

Mould

Vertical Mixer

Horizontal Mixer

Air Cooler

Pneumatic Punching

Hdpe Air Ring With Double Tuyere

Reducer

Servo Motor

RECOMMENDED MODELS

Opp Bag Making Machine

Fully Automatic Woven Bag Cutting, Sewing And Printing All-in-one Machine

Bag Width:450-800mm

Bag Length:550-1300mm

Substrate Specifications:∅1100x1200mm

Production Speed:23-45Bag/min

Non-woven high-speed T-shirt Bag Making Machine

Bag Width:200mm-600mm

Bag Length:200mm-999mm

Thickness:18-90g

Production Speed:50-120pcs/min

PERHAPS YOU HAVE OTHER BAG MAKING NEEDS?

In order to ensure that the production fully meets your needs, we also provide professional bag-making machine customization service, which can be adjusted individually according to your actual production needs, including special sizes, material adaptation and function expansion, etc., to ensure that the equipment perfectly matches your production requirements.
